Technical Specifications |
|
| CONVERTER | |
| AC Input Voltage | phase / 3 phase input and output 230 V 415V to 25% |
| Frequency Variation | 5Hz |
| Frequency | 50 Hz |
| INVERTER | |
| AC Output | Single phase output |
| Rating | Continuous |
| Technology, IGBT | High Frequency APWM |
| Voltage | 220V/230V |
| Frequency | 50 Hz |
| Regulation | 0.005% |
| Efficiency | Better than 95% |
| Wave Form | Sine wave |
| Defloration | Less than 1% on line load |
| Transient Voltage Variation | 5 Volts |
| Recovery | Less than one cycle |
| Rate Power Factor | 0.65 to 1.00 |
| Over load capacity | 120% for 10 min, 150% for 1 min |
| Cooling system | Forced Air |
| BATTERY | All make |
| Charger | Automatic Boost gum flot charger |
| BY PASS | Manual / Statics |
| Meters | Output AC Vge, Output Frequency, DC Vge, Output CT |
| Audio Alarm | Warning Buzzer for Battery Low |
| Indication | Mains 'ON' Inverter 'ON' Battery Low, over load & Short Ckt Trip |
| Production | Battery short by HRC Fuse Change Over Load Trip Change Circuit, Battery Trip |
| Operation Temperature | 0 to 50C |
| Operation Humidity | 20% to 90% |
| Audible Noise | Less than 50 db |
